Step across a ten foot deep front porch to get into this good looking modern Farmhouse home plan.
The foyer immediately opens up to the spacious great room with views extending out to the rear covered porch beyond.
Barn doors on the left slide open to reveal a quiet study with a tray ceiling.
More barn doors are used to close off the giant walk-in pantry.
In the kitchen, a big island has room to seat five people and the dining area is brightened by glass on three sides.
Homeowners will love their big vaulted master suite that is the only bedroom on this floor.
Upstairs, three additional bedrooms have easy access to a washer/dryer closet in the hall.
Finish the bonus space to suit your needs.

What’s Included

All four elevations (two pages)
Main level floor plan
Second level floor plan
Foundation plan
Foundation details
Cross sections
Roof plan
Electrical plan

What’s Not Included

Architectural or Engineering Stamp – handled locally if required
Site Plan – handled locally when required
Mechanical Drawings (location of heating and air equipment and duct work) – your subcontractors handle this
Plumbing Drawings (drawings showing the actual plumbing pipe sizes and locations) – your subcontractors handle this
Energy Calculations – handled locally when required

Square Footage Breakdown

Total Heated Area

2,528 sq. ft.

1st Floor

1,732 sq. ft.

2nd Floor

796 sq. ft.

Basement Unfinished

1,732 sq. ft.

Bonus

430 sq. ft.

Porch, Front

328 sq. ft.

Porch, Rear

285 sq. ft.

Beds/Baths

Bedrooms

Full bathrooms

Half bathrooms

Foundation Type

Standard Foundations

Crawl

Optional Foundations:

Walkout, Basement, Slab

Exterior Walls

2×6

Dimensions

Width

72′ 0″

Depth

65′ 2″

Max Ridge Height

32′ 0″

Garage

Type

Attached

Area

794 sq. ft.

Count

3 Cars

Entry Location

Side

Ceiling Heights

First Floor

9′

Second Floor

8′

Roof Details

Primary Pitch

14 on 12

Framing Type

Truss
